Filling Machine WTF-4000B

Filling Machine WTF-6000B The equipment is used in production of non -soda drink of fruit juice, fruit wine, minerals and pure water packed in polyester bottles. Washing, filling and capping are inergrated in one machine.The most advanced technology from Japan and Germany is adopted in the dedign. The gravity fixed liquid surface filling is uesd. The filling is fast, the amount of liquid is accurately controlled and the fropping and leakage are avoided.Spring cramps are used in the bottle washing process. The empty bottles can be turned over 180 along the convey belt. There are two times of internal and external washing, the efficency of bottle washing is high.The magnetic torque is uesd for screw capping. The power of screw capping can be adjusted without steps. The power of the screw capping can also be fixed, and the caps will not be damaged, the capping is reliable.The whole machine is controlled by PLC with touch- screen as the human -machine interface. The amount of the drinks in the storage tank can be controlled automatically. The filling and capping will be stopped automatically when there is no bottle.When bottles are cramped wrongly or when caps are not available, the machine can be stopped automatically.The frequency changing technology is used to adjust the operation speed steplessly. The production capacity can be displayed digitally and can be adjusted conveniently.Model WT 12-12-5 WT18-18-6 WT24-24-8 Prouction capacity (600m)(b/h): 4000 6000 8000 Polyester Bottle Standard(mm): Bottle dia. 50-100, cap (Height)150-320 Water pressure of washing bottle(Mpa) 0.18 Water consumption for water bottle(kg/h): 800, 1600, 2500 Total Weight(kg) 2500, 3500, 5500, Dimension(L*w*h)(mm): 2300*1550*2200, 2350*1650*2200, 3200*2100*2250
